NEOFLUX PRO-L ONYX STATIC WHITE
Neoflux Pro is the next generation solution for achieving seamless lines of direct view lighting for any architectural-grade install. UV, flame, and saltwater resistant, Neoflux Pro is not only durable, but easy to install. Featuring multiple power feed options, in-field customization makes for a versatile option for any interior or exterior application.
- Static white lateral (side bend) LED neon
- Available in 2700K, 3000K, and 4000K
- 90+ color rendering index
- Lumen output performance up to 32Lm per foot
- Cuttable every 1.97” with 16.4ft max run
- UV, flame, and saltwater resistant
- IP67 rating featuring sealed silicone jacketing
- Dimmable (5-100%) with most ELV and TRIAC dimmers
- cULus Listed for indoor and outdoor wet locations
- 54,000 hours rated life
Series
NFPROL-ONYX
Voltage
24V DC
CCT
2700K / 3000K / 4000K
Wattage
3.05W/ft
Lumens
Up to 32Lm/ft
Max Run
16.4ft
Cut Increments
Every 1.97"
IP Rating
IP67 - Jacketed
Dimmable
(5-100%) with most ELV and TRIAC dimmers
Rating
cULus Listed - Wet Location
Rated Life
54,000 hours
PZM-NFPROL-ONYX-CHAN-1M
1m Black Channel 17.3mm W x 21.1mm H
PZM-ADPT-DRJ-30-24
PZM-ADPT-DRJ-60-24
PZM-ADPT-DRJ-96-24
PZM-ADPT-DRJ-192-24
PZM-ADPT-DRJ-288-24
